Tractionator RallZ – Tubeless
| Code Size Use
Homologation |
Type TL / TT |
Homologation | Load / Speed Index |
M+S/MST | Standard Measuring Rim (Inch) |
Permissible/ Recommended (Inch) |
ETRTO Standard Overall Diam (mm +/-) |
ETRTO Standard Overall Width (mm+/-) |
Tread Depth at Centre (mm) |
Position |
|---|---|---|---|---|---|---|---|---|---|---|
| TRXQ 90/90-21 | TL | DOT ECER75 | 54 Q | M+S | 2.50 | 2.15 | 695 | 99 | 12 | Front |
| TRXQ 110/80B19 | TL | DOT ECER75 | 59 Q | M+S | 2.50 | – | 659 | 109 | 10 | Front |
| TRXQ 120/70B19 | TL | DOT ECER75 | 60 Q | M+S | 3.50 | – | 651 | 122 | 10 | Front |
| TRXQ 150/70B18 | TL | DOT ECER75 | 70 Q | M+S | 4.25 | 4.50 | 667 | 151 | 15 | Rear |
| TRXQ 150/70B17 | TL | DOT ECER75 | 69 Q | M+S | 4.25 | – | 642 | 151 | 15 | Rear |
| TRXQ 170/60B17 | TL | DOT ECER75 | 72 Q | M+S | 4.50 | – | 636 | 168 | 15.5 | Rear |
Tractionator RallZ – Tube Type
| Code Size Use
Homologation |
Type TL / TT |
Homologation | Load / Speed Index |
M+S/MST | Standard Measuring Rim (Inch) |
Permissible / Recommended (Inch) |
ETRTO Standard Overall Diam (mm +/-) |
ETRTO Standard Overall Width (mm+/-) |
Tread Depth at Centre (mm) |
Position |
|---|---|---|---|---|---|---|---|---|---|---|
| TRXR 90/90-21 | TT | DOT ECER75 | 54 R | MST | 1.85 | 1.60 | 695 | 90 | 12 | Front |
| TRXR 120/90-18 | TT | DOT ECER75 | 65 R | MST | 2.15 | 2.50 | 673 | 119 | 14.5 | Rear |
| TRXR 140/80-18 | TT | DOT ECER75 | 70 R | MST | 2.15 | 2.50 | 681 | 142 | 14.5 | Rear |
| TRXR 130/80-17 | TT | DOT ECER75 | 65 R | MST | 3.00 | – | 640 | 129 | 15 | Rear |
